SunSet 10G is a handheld test device that supports SDH and SONET testing and analysis, covering all test interfaces including core and metropolitan SDH/SONET rings and branches. It has all SDH, SONET, PDH, T-carrier optical signal and electrical signal testing functions, which greatly improves the efficiency and saves costs of testing and training.
The SunSet 10G is a handheld optical test instrument supporting SDH/SONET, PDH, and T‑Carrier interfaces. It offers end‑to‑end BERT testing, APS monitoring, and alarm functions for a range of data rates from 1.5 Mbps up to 10 Gbps.
The manual details optical port types, wavelength performance, electrical specifications, environmental limits, and available accessories. It also includes installation, operation, and troubleshooting guidance for field use. This manual is written in Japanese.
| Bit rate | 9.95328 Gbps ±4.5 ppm |
|---|---|
| 1550 nm output power (short distance) | -4 to -1 dBm |
| 1310 nm output power (mid distance) | -1 to +2 dBm |
| Maximum input power | +7 dBm |
| Operating temperature | 0 °C to 45 °C |
| Dimensions | 11 × 9 × 28.5 mm |
| Weight | 2.2 kg |
The device operates at a bit rate of 9.95328 Gbps with a tolerance of ±4.5 ppm.
It supports 1550 nm (short‑distance output power –4 to –1 dBm) and 1310 nm (mid‑distance output power –1 to +2 dBm).
The unit can operate from 0 °C up to 45 °C.
The device measures 11 × 9 × 28.5 mm.
