This manual explains the safe use of the Makita MT430 curve saw, covering safety rules, proper worksite conditions, and electrical safety. It also describes the tool’s intended applications for cutting wood, plastic, and metal, especially for curved or circular cuts.
The guide details operating procedures, including power switch handling, speed control, blade installation, tilt‑cutting angles, and maintenance tasks such as carbon‑brush replacement and blade cleaning. It lists the required safety equipment and outlines how to service the tool at authorized Makita service centers. This manual is written in Chinese.
| Model | MT430 |
|---|---|
| Stroke length | 26 mm |
| Maximum wood cutting depth | 55 mm (2‑1/4") |
| Blade thickness | 6 mm (1/4") |
| Overall length | 219 mm (8‑5/89") |
| Net weight | 2.6 kg (5.71 lb) |
The MT430 can cut wood up to 55 mm (2‑1/4").
Inspect the brushes regularly and replace them when wear reaches the limit line.
Always wear safety glasses (or goggles) and other protective gear such as a face mask or helmet as needed.
