BandLuxe™ C120 is a USB interface product that supports 2G, 3G, and 3.5G standards. It features SMS transmission, compatibility with multiple operating systems, and a multi-language interface.
This manual covers the complete installation process for the BandLuxe C120, including SIM insertion, USB connection, and running the HSDPA Utility installer. It also explains how to use the Connection Manager, configure APN settings, and monitor data usage.
Safety information, regulatory compliance (CE, FCC) and handling warnings are detailed, along with a full list of technical specifications such as supported operating systems, interfaces, dimensions, weight, memory, and wireless frequencies. This manual is written in Chinese.
| Supported Operating Systems | Windows 2000 SP4+, XP SP2+, Vista |
|---|---|
| Interface | 2 USB ports |
| Dimensions | 88 x 28 x 17.42 mm |
| GSM Frequencies | 850, 900, 1800, 1900 MHz |
| UMTS Frequency | 2100 MHz |
| Maximum Download Speed | 7.2 Mbps |
Insert the SIM card into the SIM slot, connect the C120 to a PC via USB, then run the BandLuxe HSDPA Utility installer and follow the InstallShield wizard prompts.
Do not use the device in environments with explosive or flammable gases, near high‑power radio equipment, or in aircraft without turning it off, and follow the CE and FCC guidelines.
The C120 supports GSM bands 850, 900, 1800, 1900 MHz and UMTS 2100 MHz.
The device measures 88 × 28 × 17.42 mm and weighs 37 g.
