AUTOTUBE-100 is a product developed by HI-LO SYSTEM RESEARCH CO., LTD. This manual provides the user manual for the product, including machine accessories, specifications, basic installation, control interface and function operation instructions, operation flow view and adjustment calibration, testing, formal startup, warning message instructions, simple troubleshooting, maintenance matters, etc.
The AUTOTUBE-100 is an industrial tube‑forming machine produced by HI‑LO System Research Co., Ltd. This manual supplies detailed information for owners and service technicians, covering accessories, specifications, power requirements, control interface functions, and safety precautions.
Key sections include a complete parts list, step‑by‑step operation and calibration procedures, programming and verification tests, as well as troubleshooting tips and maintenance items. The document also outlines air‑system requirements and guidelines for selecting appropriate air‑compressor equipment. This manual is written in Chinese.
| Input voltage | 110‑240 V, 50‑60 Hz |
|---|---|
| Power consumption | 108 A |
| Internal DC voltage | 9‑24 V |
| Air pressure | 5 bar (0.5 MPa) |
| Air consumption (machine) | 7.4 L/min |
| Dimensions (W×D×H) | 320 mm × 450 mm × 525 mm (800 mm with tower light) |
| Weight | <15 kg |
| Cycle time | 5 seconds |
| Throughput | 4500 / 3300 / 2600 units per hour |
The manual specifies an input voltage range of 110‑240 V at 50‑60 Hz.
The AUTOTUBE-100 consumes 7.4 L of air per minute while operating.
Its dimensions are 320 mm wide, 450 mm deep, and 525 mm high (800 mm high with the tower light installed).
