This manual introduces the hardware introduction, system introduction, homepage description, integration page description, detailed data, data query, system maintenance, etc. of the GBox Logger system, for the user reference.
The GBox Logger is a data‑aggregation device that can connect to up to 10 inverters and one environmental sensor. It records data on a storage device and presents it through a web‑based interface accessible via the default IP address 192.168.0.100.
The manual walks users through hardware description, system configuration, main and integration pages, detailed data views, data query procedures, and system maintenance tasks such as password changes and rebooting. Appendices list data‑display formats and the default register definitions for the logger, Phoenixtec inverters, and Phase Sensors. This manual is written in Chinese.
| Default IP address | 192.168.0.100 |
|---|---|
| Supported inverter connections | 1~10 |
Connect the logger to the network, open a web browser, and enter http://192.168.0.100 in the address bar.
Click the Restart button to reboot the system so the new settings take effect.
