PCI-58XX CAN interface card is a stable and reliable CAN interface card that supports bit rates between 5Kbps and 1Mbps, provides drivers for multiple operating systems, and comes with VB, VC, C++Builder, Dephi, VB2003, Labview application routines. It can truly meet the needs of customers for various applications and provide reliable and efficient solutions for industrial communication CAN networks.
This manual describes the PCI-58XX CAN interface card, a PCI‑based device that supports 1‑2 CAN channels and complies with CAN 2.0A/B standards. It outlines the product’s performance specifications, including temperature ranges, baud rates, and isolation voltage.
The document includes detailed hardware installation steps, driver installation procedures for Windows XP and Windows 2000, and programming examples for VC++, C++ Builder, and VB. Technical support information and warranty details are also provided. This manual is written in Chinese.
| Operating temperature | -25°C to +70°C |
|---|---|
| Storage temperature | -35°C to +85°C |
| Maximum CAN bus speed | 3000 frames/s |
| Supported baud rates | 10 Kbps – 1 Mbps |
| Number of CAN channels | 1‑2 |
| Isolation voltage | 2300 V |
The PCI-58XX supports 1 to 2 CAN channels.
It operates from –25 °C to +70 °C (storage –35 °C to +85 °C).
The interface provides an isolation voltage of 2300 V.
