LW-103 user manual, introduces the product's unpacking check, safety instructions, operating instructions, installation, functional operation, channel function settings, technical parameters and company profile.
This guide covers the installation and basic operation of the ML-103 lighting unit. It includes safety notes, power requirements, and wiring instructions for DMX‑512 control.
Key sections detail the DMX‑512 pinout, connector wiring, and recommended connection methods, along with specifications such as input voltage, current draw, and operating temperature limits.
| Input Voltage | AC110/230V, 50‑60Hz |
|---|---|
| Current | 2A @ 230V |
| Operating Temperature | Up to 40 °C (base), 80 °C (max) |
Pin 1 is GND (screen), Pin 2 is Signal (‑), Pin 3 is Signal (+), with pins 4 and 5 not connected.
The unit operates on AC 110 V to 230 V at 50‑60 Hz.
