This user manual provides information on ASDA-AB series servo drives and ECMA series servo motors, including installation and inspection, composition explanation, steps for trial operation, introduction to control functions and adjustment methods, parameter explanation, communication protocol explanation, detection and maintenance, troubleshooting, and application examples.
This manual provides comprehensive instructions for the Delta ASDA-AB series servo drives. It includes safety precautions, installation guidelines, wiring diagrams, and detailed operating procedures for both 220 V and 110 V versions.
The document also describes the drive’s technical features such as DSP‑based control, IGBT output, and compatibility with three‑phase permanent‑magnet synchronous motors (PMSM). Reference tables list model numbers, power ratings, and connector specifications. This manual is written in Chinese.
| Control processor | Digital Signal Processor (DSP) |
|---|---|
| Power output device | IGBT |
| Enclosure rating | UL50 Type 1 / NEMA 250 Type 1 |
| Voltage versions | 220 V series and 110 V series |
| Power rating – model ASD‑A2023‑AB | 2 kW |
| Power rating – model ASD‑A3023‑AB | 3 kW |
| I/O connector | 50‑pin CN1 connector |
It is designed to drive three‑phase permanent‑magnet synchronous motors (PMSM).
