SSC-G923/G913/G928/G918 color video camera is a color video camera with a 1/3 inch Super HAD CCD IITM camera. It has high resolution, wide dynamic range, high sensitivity, noise reduction, motion detection function or face detection function alarm output, day/night function, automatic white balance tracking and adjustment (ATW/ATW-PRO), DC controlled auto iris lens capability, video controlled auto iris lens capability (for the SSC-G923/G928), backlight compensation through center measurement, line lock function for synchronizing through AC power source, and easy setup using English and Chinese language on-screen menu.
The Sony SSC‑G923/G913 and SSC‑G928/G918 cameras are equipped with a 1/3 inch Super HAD CCD and offer high resolution, wide dynamic range, and automatic white‑balance features. The document explains power requirements, handling precautions, and recommended operating environments.
Installation steps cover mounting, wiring, lens attachment, and safety measures such as fall‑prevention rope and grounding. Technical specifications, cleaning guidelines, and troubleshooting notes are also included.
| Image sensor | 1/3 inch Super HAD CCD |
|---|---|
| Effective picture elements | 976 × 582 (SSC‑G923/G928), 752 × 582 (SSC‑G913/G918) |
| Horizontal resolution | 650 lines (SSC‑G923/G928), 540 lines (SSC‑G913/G918) |
| Minimum illumination (color) | 0.22 lx at F1.2 (50 IRE, AGC ON, Turbo mode) |
| Video output | 1 Vp‑p, 75 Ω, negative sync |
| Power consumption | 2.8 W (SSC‑G923), 3.5 W (SSC‑G928), 2.4 W (SSC‑G913), 2.8 W (SSC‑G918) |
| Operating temperature | –10 °C to +50 °C (14 °F to 122 °F) |
| Dimensions (W × H × D) | 63 × 57 × 124 mm |
| Mass | ≈ 400 g (SSC‑G923/G913), ≈ 420 g (SSC‑G928/G918) |
| Power supply | AC 24 V (50 Hz) / DC 12 V (SSC‑G923/G913); AC 220‑240 V (50 Hz) (SSC‑G928/G918) |
It can be powered by either AC 24 V (50 Hz) or DC 12 V.
0.22 lx at F1.2 (50 IRE, AGC ON, Turbo mode).
Approximately 400 g for the SSC‑G923/G913 models and 420 g for the SSC‑G928/G918 models.
The video output is 1 Vp‑p, 75 Ω, with negative sync.
