This document is an explanation of the DIGITAL MIXING ENGINE SATELLITE by JA. It includes the explanation of graphical symbols and important safety instructions for the product.
The Yamaha DME Satellite series is a professional digital mixing engine. The manual begins with safety warnings, proper handling, and power‑supply precautions to prevent electric shock, fire, or damage.
It then describes the three model variants, their analog I/O configurations, network and USB connections, audio routing, MIDI functionality, rack‑mount guidelines, and service information, enabling users to install, configure, and operate the unit safely and efficiently. This manual is written in Japanese.
| DME4io-ES analog I/O | 4 inputs and 4 outputs |
|---|---|
| Network interface | 100Base‑TX Ethernet, RJ‑45 connector |
Leave at least 10 cm between the rack back and the wall to ensure proper ventilation.
