APEM Manuals

This manual is APEM's toggle switch product catalog, which details the product's specifications, model numbers, features, etc.

This document is about the specifications of APEM's pushbutton switches, including product model, size, rated voltage, rated current, etc.

The document introduces a 4x4 matrix keypad with insert pockets, standard 16-key design, polymer tactile dome and upper/lower circuits. It has a thickness of 1.50mm and 4 inserts with black graphics on a silver background. The keypad features a silver unembossed border and black background with 16 clear windows of 12.60mm diameter. Detailed mechanical, electrical, and environmental specifications are provided.

The P60A and P60AS series rotary DIP switches are compact switches with 10 or 16 positions. They offer high reliability and long life, and can operate in a temperature range of -20°C to 85°C. The switches are suitable for hand soldering, wave soldering, and reflow soldering. They feature a 4 + 1 terminal layout, complete sealing for process compatibility, and precision designed detent action for clockwise or counterclockwise setting.

APEM CR65 series rotary code switches are available with screwdriver or accessory actuation, and with straight or right angle terminals. The voltage range is 24 VDC max, static load is 400 mA max, dynamic load is 150 mA max. The switch has an operating temperature of -20 to +70 °C and an expected life of 10,000 cycles.

The document describes the features and characteristics of a product.

The P36 series rotary DIP switches are an ultra-compact switch with a 3 + 3 terminal layout, completely sealed for process compatibility, with 10 or 16 positions, precision designed detent action, thru-hole (P36 Series) and SMT (P36S Series) models, high reliability and long life, clockwise or counterclockwise settable, solder coated terminals.

PT65 series rotary DIP switches have 3+3 terminal layout, completely sealed, 4, 6, 8, 10 or 16 positions and extensive coding.

This document introduces the TP series of subminiature washable momentary pushbutton switches, including electrical functions, connector and terminal materials, plunger types, special options, etc.

The IA series low profile pushbutton switches are IP67 front panel sealed, resistant to frost, sand and hydrocarbons, and have good tactile feedback.

A03 SERIES ILLUMINATED OR NON-ILLUMINATED PUSHBUTTON SWITCHES & INDICATORS

The document provides information about the G-16 APEM A02 series illuminated or non-illuminated pushbutton switches, including their panel cut-out dimensions and assembly requirements.
