Featured Huacecs manuals
Huacecs 9000 Series Support Strain Gauge Installation and Use Manual
The document provides technical specifications and operating instructions for the Huacecs 9000 series vibrating wire support strain gauge. It explains that the device measures resonance frequency changes in a steel string to calculate strain caused by deformation of the surrounding metal tube under external force or temperature influence.
Detailed guidance is provided on installing the instrument on both steel structures and concrete surfaces, including specific steps for welding mounting blocks and using anchor heads. The manual also covers cable extension techniques, initial reading adjustments (targeting 650 for tension or 950 for compression), and data processing methods. This manual is written in Chinese.
Covers: Introduction · Technical Parameters · Instrument Installation · Preliminary Inspection · Cable Extension · Strain Gauge Installation on Steel
Latest Huacecs manuals
Huacecs 9000 Series Support Strain Gauge Installation and Use Manual
User Manual 13 pages · 1.2 MB · ZHThis manual covers the installation, adjustment, reading, and calculation procedures for the Huacecs 9000 series vibrating wire support strain gauge.
Which document do I need?
User Manual
Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.
Questions answered in Huacecs manuals
What is the measurement range of the Huacecs 9000 strain gauge?
The measurement range is 3000 microstrain (με).
From: Huacecs 9000 Series Support Strain Gauge Installation and Use Manual
How should the instrument be adjusted for measuring compression strain?
Push the active end of the strain gauge outward slightly to adjust the reading to approximately 950.
From: Huacecs 9000 Series Support Strain Gauge Installation and Use Manual
