Featured ARIANESPACE manuals
ARIANESPACE ASAP 5 Structure for Auxiliary Payload User's Manual
This document serves as the User's Manual for the ASAP 5 (Ariane 5 Structure for Auxiliary Payload) system, issued by ARIANESPACE in May 2000. It is intended to provide users with mandatory technical information to assess the compatibility of an Auxiliary Payload with the ASAP 5 launch system and to prepare all necessary technical and operational documentation for a launch. This manual is written in French.
Covers: Introduction · Description of the Structure called ASAP 5 · Auxiliary payload design and dimensioning data · Interfaces for micro Auxiliary Payload · Interfaces for mini Auxiliary Payload · Dimensioning and qualification of micro Auxiliary Payloads
Latest ARIANESPACE manuals
ARIANESPACE ASAP 5 Structure for Auxiliary Payload User's Manual
User Manual 72 pages · 1.5 MB · FRThis manual provides technical information for assessing the compatibility of an Auxiliary Payload with the ASAP 5 launch system and preparing operational…
Which document do I need?
User Manual
Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.
Questions answered in ARIANESPACE manuals
What mass limits apply to micro and mini Auxiliary Payloads for the ASAP 5 system?
The system is designed for micro payloads with a maximum mass of 120 kg and mini payloads ranging from 120 kg up to 300 kg.
From: ARIANESPACE ASAP 5 Structure for Auxiliary Payload User's Manual
What are the maximum masses for micro and mini payloads in the different ASAP 5 configurations?
The configuration carrying up to 8 micro payloads supports a maximum mass of 120 kg, while the one for up to 4 mini payloads supports a maximum mass of 300 kg.
From: ARIANESPACE ASAP 5 Structure for Auxiliary Payload User's Manual
