Featured CTC Control manuals
CTC Control 5100-C Digital Output Module Data Sheet
This document is a data sheet for the CTC Control 5100-C Digital Output Module. The device provides eight +24 VDC sourcing digital outputs utilizing internal PNP transistors connected to the controller's power supply. Each output features an individual red LED status indicator located on the field side of the control circuit.
Covers: Description · Specifications · Module Identification · Application Information · I/O Terminations
Latest CTC Control manuals
CTC Control 5100-C Digital Output Module Data Sheet
Datasheet 2 pages · 166 KB · ENData sheet for the CTC Control 5100-C Digital Output Module, an eight-channel +24 VDC sourcing module with LED status indicators.
Which document do I need?
Datasheet
Ratings, dimensions and ordering codes, for selection and design work.
Questions answered in CTC Control manuals
What type of digital outputs does this module provide?
The module provides eight +24 VDC sourcing digital outputs that use an internal PNP transistor connected to the controller's power supply.
What is the maximum current any single output can source?
Each individual output can source a maximum of 375 mA.
