Key facts
- Manuals
- 1
- Languages
- EN
- Last added
- 2026-10-17
Featured 40MAQ manuals
40MAQ High Wall Ductless System Service Manual Sizes 09 to 36
The document is a technical service guide for the 40MAQ High Wall Ductless System indoor fan coil units. It provides essential safety considerations, unit nomenclature, and detailed specifications including electrical data, dimensions, and clearances for various model sizes ranging from 9 to 36 tons.
Covers: Safety Considerations · Model Nomenclatures · Specifications · Compatibility · Dimensions · Electrical Data
Latest 40MAQ manuals
40MAQ High Wall Ductless System Service Manual Sizes 09 to 36
Service Manual 42 pages · 2.1 MB · ENThis service manual covers installation, wiring, troubleshooting, and disassembly for the 40MAQ High Wall Ductless System indoor units (Sizes 09-36).
Which document do I need?
Service Manual
Disassembly, diagnostics and part numbers, for repair.
Questions answered in 40MAQ manuals
What are the compatible outdoor units for single zone systems?
Compatible single zone outdoor units include models such as 38MAQB09-1, 38MAQB12-1, and 38MAQB09R-1.
From: 40MAQ High Wall Ductless System Service Manual Sizes 09 to 36
What type of wire must be used for communication?
A separate shielded stranded copper conductor with a 600 volt rating and double insulated copper wire is required.
From: 40MAQ High Wall Ductless System Service Manual Sizes 09 to 36
