Featured ViewSharp manuals
ViewSharp VS48272M43 Color LCD Module User Manual
The ViewSharp VS48272M43 is a 4.3-inch color liquid crystal display module featuring a 480x272 pixel resolution and support for 65K colors. It supports both 8-bit and 16-bit data bus interfaces (8080/6800 modes) as well as SPI serial interfaces. The module includes a Block Transfer Engine (BTE) for efficient graphic rendering and supports up to 2x16M of FLASH storage for image caching. This manual is written in Chinese.
Covers: Introduction · Electrical Characteristics · Pin Description · Connection and Transmission Protocol · Register Description · Function Description
Latest ViewSharp manuals
ViewSharp VS48272M43 Color LCD Module User Manual
User Manual 165 pages · 8.2 MB · ZHThis manual covers the operation, electrical characteristics, and programming of the ViewSharp VS48272M43 4.3-inch color LCD module.
Which document do I need?
User Manual
Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.
Questions answered in ViewSharp manuals
What data bus widths does the VS48272M43 support?
The module supports both 8-bit and 16-bit data bus interfaces.
Does the module support SPI communication?
Yes, it supports 3-wire and 4-wire SPI serial interfaces.
