Key facts
- Manuals
- 1
- Languages
- ZH
- Last added
- 2026-10-17
Featured YHWKGS manuals
YHWKGS YHWKGS100 Series DC/DC Module Datasheet
This document is a technical datasheet for the YHWKGS100 series of 1/4 brick isolated DC/DC module power supplies. It details product features such as ultra-wide input voltage ranges (4:1), high efficiency up to 94%, and robust protection mechanisms including over-voltage, over-current, and thermal shutdown. This manual is written in Chinese.
Covers: Product Features · Selection Table · Input Characteristics · Output Characteristics · General Specifications · Physical Characteristics
Latest YHWKGS manuals
YHWKGS YHWKGS100 Series DC/DC Module Datasheet
Datasheet 7 pages · 704 KB · ZHTechnical datasheet for the YHWKGS100 series 1/4 brick isolated DC/DC module power supplies, covering specifications, application circuits, and EMC solutions.
Which document do I need?
Datasheet
Ratings, dimensions and ordering codes, for selection and design work.
Questions answered in YHWKGS manuals
Is hot-plugging supported?
No, the product does not support hot plugging.
What is the maximum operating temperature for the YHWKGS100-48S05(S/Z) module?
The module operates within a temperature range of -40℃ to +85℃.
