Featured Detair manuals
Detair XSR70A Color Patrol Recorder User Manual
The Detair XSR70A Color Patrol Recorder is a device designed for industrial automation control, featuring a true-color TFT LCD screen, an ARM microprocessor, and a large-capacity FLASH memory. It supports various input signals including DC current, DC voltage, thermistors, thermocouples, and remote pressure gauges, with measurement accuracy of ±0.2% F·S.
The device allows users to configure channels, set alarm limits, and manage data accumulation. It offers multiple display modes such as digital, bar chart, real-time curve, and recall curve. Data can be exported to a computer via USB or RS232/RS485 interfaces. The manual provides detailed instructions on installation, wiring, parameter settings, and common fault analysis. This manual is written in Chinese.
Covers: Overview · Model Specifications · Technical Specifications · Installation and Wiring · Function Description · Instrument Operation
Latest Detair manuals
Detair XSR70A Color Patrol Recorder User Manual
User Manual 40 pages · 497 KB · ZHThis manual covers the operation, installation, configuration, and troubleshooting of the Detair XSR70A Color Patrol Recorder for industrial automation.
Which document do I need?
User Manual
Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.
Questions answered in Detair manuals
What are the supported input signal types?
The device supports DC current, DC voltage, thermistors, thermocouples, and remote pressure gauges.
What is the measurement accuracy of the recorder?
The measurement, display, and recording accuracy is ±0.2% F·S.
