Featured Pangu manuals
Pangu KT100R Instrument User Manual
The Pangu KT100R is a digital instrument featuring a 3.5-inch TFT color LCD display with a resolution of 320x240. It supports various input configurations including analog signals, alarm outputs, and communication interfaces such as RS232C/RS485. The device allows for data recording, backup to USB or SD cards (optional), and real-time curve visualization. This manual is written in Chinese.
Covers: Function Overview · Safety Precautions · Package Contents · Display Functions · System Configuration · Input/Output Settings
Latest Pangu manuals
Pangu KT100R Instrument User Manual
User Manual 143 pages · 2.8 MB · ZHThis manual provides operating instructions, setup guides, wiring diagrams, and troubleshooting procedures for the Pangu KT100R instrument.
Which document do I need?
User Manual
Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.
Questions answered in Pangu manuals
What is the resolution of the instrument's display?
The instrument features a 3.5-inch TFT true-color liquid crystal display with a resolution of 320×240.
What are the required dimensions for the panel cutout?
The instrument requires a panel cutout size of 92 mm by 92 mm.
