Featured R16 manuals
R16 R16-10DB UHF Reader User Manual
This document is the user manual for the R16-10DB ultra-high frequency (UHF) electronic label reader. The device supports multiple protocols including ISO18000-6C (EPC G2) and features a built-in circularly polarized antenna with 10dBi gain. It is designed for applications such as vehicle access control, toll collection, and logistics monitoring, with a maximum stable read distance of over 12 meters. This manual is written in Chinese.
Covers: Introduction · Technical Parameters · Connection and Wiring · Operating Modes · Reader Configuration · Installation Methods
Latest R16 manuals
R16 R16-10DB UHF Reader User Manual
User Manual 9 pages · 732 KB · ZHUser manual for the R16-10DB ultra-high frequency electronic label reader, covering installation, configuration, and secondary development.
Which document do I need?
User Manual
Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.
Questions answered in R16 manuals
What is the maximum stable read distance?
The stable read distance is greater than 12 meters, depending on the tag and site environment.
Does the device support secondary development?
Yes, it provides an SDK development package with example routines for C#, VC, VB, Java, and Delphi.
