Key facts
- Manuals
- 1
- Languages
- ZH
- Last added
- 2026-10-17
Featured Hanschip manuals
Hanschip LM1086 1.5A LDO Regulator Datasheet
The LM1086 is a positive voltage output low dropout three-terminal linear regulator circuit manufactured by Hanschip. It is designed for various electronic products and offers fixed output voltages of 3.3V and 5.0V, as well as an adjustable version with 1% voltage accuracy. The device features low dropout voltage, current limiting, and thermal shutdown protection. This manual is written in Chinese.
Covers: Features · Applications · Ordering Information · Product Description · Absolute Maximum Ratings · Recommended Operating Conditions
Latest Hanschip manuals
Hanschip LM1086 1.5A LDO Regulator Datasheet
Datasheet 9 pages · 611 KB · ZHThis datasheet describes the Hanschip LM1086, a 1.5A low-dropout linear regulator with fixed 3.3V/5.0V and adjustable output options.
Which document do I need?
Datasheet
Ratings, dimensions and ordering codes, for selection and design work.
Questions answered in Hanschip manuals
What are the fixed output voltage options for the LM1086?
The LM1086 offers fixed output voltages of 3.3V and 5.0V.
What is the maximum output current of the LM1086?
The maximum output current is 1.5A.
