Featured JINHANIC manuals
JINHANIC ADO20 Series Tablet Automotive Oscilloscope User Manual
This manual provides operating instructions for the JINHANIC ADO20 series digital handheld tablet automotive oscilloscope. It covers safety precautions, quick start guides, and detailed operation for automotive diagnostics, general oscilloscope functions, and a built-in multimeter. The device features a 7-inch touch screen and supports various automotive sensor and actuator measurements. This manual is written in Chinese.
Covers: Safety Precautions · Quick Start Guide · Automotive Oscilloscope Functions · General Oscilloscope Functions · Multimeter Functions · Home Screen Functions
Latest JINHANIC manuals
JINHANIC ADO20 Series Tablet Automotive Oscilloscope User Manual
User Manual 78 pages · 5.4 MB · ZHUser manual for the JINHANIC ADO20 series tablet automotive oscilloscope, covering safety, operation, automotive diagnostics, and troubleshooting.
Which document do I need?
User Manual
Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.
Questions answered in JINHANIC manuals
What is the maximum input voltage for the ADO20 oscilloscope?
The maximum input voltage is 400V when using a 10X probe.
From: JINHANIC ADO20 Series Tablet Automotive Oscilloscope User Manual
What is the sampling rate of the ADO20 series?
The real-time sampling rate is 100 MSa/s.
From: JINHANIC ADO20 Series Tablet Automotive Oscilloscope User Manual
