Featured Beijing Century Bingyang Technology manuals
BY-100 Equipment Inspection Doctor User Manual
The BY-100 Equipment Inspection Doctor is a comprehensive diagnostic system combining a handheld computer with specialized vibration signal processing boards. It serves as an assistant for equipment diagnosis and maintenance in the field, offering high cost-performance through tight hardware-software integration.
The system supports analysis of rotor systems (including imbalance, misalignment, and oil whip), rolling bearings (damage, friction, lubrication issues), and gearboxes (eccentricity, wear, pitch error). It also includes temperature acquisition capabilities to monitor equipment health. This manual is written in Chinese.
Covers: System Introduction · Hardware Composition · Installation Settings · Software Operation · Data Management · Signal Simulation
Latest Beijing Century Bingyang Technology manuals
BY-100 Equipment Inspection Doctor User Manual
User Manual 25 pages · 2.3 MB · ZHThis manual provides operating instructions for the BY-100 Equipment Inspection Doctor, a portable system for vibration signal acquisition and fault…
Which document do I need?
User Manual
Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.
Questions answered in Beijing Century Bingyang Technology manuals
How long can the BY-100 operate on a single charge?
The device can operate for 6.5 hours on a single charge.
What are the available options for signal frequency analysis?
The analysis frequency has eight selectable options: 100, 200, 500, 1K, 2K, 5K, 10K, and 20K.
