Key facts
- Manuals
- 1
- Languages
- ZH
- Last added
- 2026-10-16
Featured YueqingYulin manuals
YueqingYulin FLM22-11DMJ Emergency Stop Button Specification Sheet
This document is a specification sheet for the YueqingYulin FLM22-11DMJ, a large-head emergency stop button with metal contacts. It provides details on the product's construction, including materials used for the housing, button, and internal components like the light source and resistors.
The sheet lists key performance parameters, such as rated voltage and current for the switch and indicator light, insulation resistance, contact resistance, and mechanical and electrical life ratings. It also specifies the operating temperature range and protection degree. This manual is written in Chinese.
Covers: Picture · Drawing · Component Material · Performance Parameter · Switch Rated Voltage · Rated Current
Latest YueqingYulin manuals
YueqingYulin FLM22-11DMJ Emergency Stop Button Specification Sheet
Datasheet 3 pages · 546 KB · ZHSpecification sheet for the YueqingYulin FLM22-11DMJ emergency stop button, detailing materials, performance parameters, and electrical ratings.
Which document do I need?
Datasheet
Ratings, dimensions and ordering codes, for selection and design work.
Questions answered in YueqingYulin manuals
What is the rated voltage for the switch?
The switch has a rated voltage of 36VDC and 250VAC.
From: YueqingYulin FLM22-11DMJ Emergency Stop Button Specification Sheet
What is the maximum operating temperature range?
The product operates in a temperature range from -25°C to +85°C.
From: YueqingYulin FLM22-11DMJ Emergency Stop Button Specification Sheet
