Featured Nanyang manuals
Nanyang TYBPE Explosion-proof Variable Speed Permanent Magnet Synchronous Motor User Manual
The Nanyang TYBPE series explosion-proof variable speed permanent magnet synchronous motors are designed for use in coal mine underground mining faces and factory environments with explosive gas mixtures. These motors comply with GB3836.1-2010 and GB3836.2-2010 standards for explosion-proof equipment, featuring explosion-proof markings such as ExdIMb and ExdⅡAT1Gb through ExdⅡBT4Gb. The series covers frame sizes from 80 to 355 and is suitable for continuous duty (S1) with rated voltages of 380V, 660V, and 1140V. This manual is written in Chinese.
Covers: Overview · Product Model and Meaning · Application Scope and Conditions · Installation Structure and Specifications · Main Structure Description · Explosion-proof Points
Latest Nanyang manuals
Nanyang TYBPE Explosion-proof Variable Speed Permanent Magnet Synchronous Motor User Manual
User Manual 15 pages · 433 KB · ZHThis manual covers the installation, operation, maintenance, and specifications of the Nanyang TYBPE series explosion-proof variable speed permanent magnet…
Which document do I need?
User Manual
Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.
Questions answered in Nanyang manuals
What are the explosion-proof ratings for this motor series?
The motors feature explosion-proof markings including ExdIMb, ExdⅡAT1Gb through ExdⅡAT4Gb, and ExdⅡBT1Gb through ExdⅡBT4Gb.
From: Nanyang TYBPE Explosion-proof Variable Speed Permanent Magnet Synchronous Motor User Manual
What is the maximum operating temperature for the motor housing?
Under rated working conditions, the maximum surface temperature of the motor housing must not exceed 150℃.
From: Nanyang TYBPE Explosion-proof Variable Speed Permanent Magnet Synchronous Motor User Manual
