Featured Hangmei manuals
Hangmei PDJK Series Thyristor Triggerer User Manual
The Hangmei PDJK series thyristor triggerer is designed for controlling various heating elements such as resistance wires, infrared lamps, silicon carbide rods, and transformers. It supports diverse input signals including 0-20mA, 4-20mA, 0-5V, and 1-5V, allowing for automatic control via PID instruments or PLCs, as well as manual operation. This manual is written in Chinese.
Covers: Features · Model Description · Main Circuit Wiring Diagrams · Control Terminal Wiring Methods · Functional Settings (DIP Switch) · Soft Start/Stop Function
Latest Hangmei manuals
Hangmei PDJK Series Thyristor Triggerer User Manual
User Manual 8 pages · 936 KB · ZHThis manual details the operation, wiring diagrams, and functional settings for Hangmei PDJK series thyristor triggerers used to control resistive and…
Which document do I need?
User Manual
Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.
Questions answered in Hangmei manuals
What input signals does the PDJK series support?
The device supports 0-20mA, 0-5V, 4-20mA, 1-5V, and other signals upon order specification.
How does the device handle phase loss?
It features missing phase detection and alarm protection, which can be configured for single or multiple phases.
