Featured Integram manuals
Integram SDPIP-100 Picture-in-Picture Processor User Manual
The Integram SDPIP-100 is a digital image processing device designed to display two camera feeds simultaneously on one monitor. It utilizes Picture-in-Picture (PIP) technology to prevent tampering with the main video feed and allows for independent channel monitoring. The device supports standard PAL-D video signals and features automatic or manual switching between channels. This manual is written in Chinese.
Covers: Product Overview · Device Appearance · Main Technical Specifications · Processor Principle Diagram · Application Areas · Installation Instructions
Latest Integram manuals
Integram SDPIP-100 Picture-in-Picture Processor User Manual
User Manual 8 pages · 171 KB · ZHThis manual describes the installation, operation, and settings for the Integram SDPIP-100 picture-in-picture processor used in surveillance systems.
Which document do I need?
User Manual
Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.
Questions answered in Integram manuals
What are the physical dimensions of the SDPIP-100?
The device measures 300mm in length, 220mm in width, and 44mm in height.
From: Integram SDPIP-100 Picture-in-Picture Processor User Manual
What is the required input power for the SDPIP-100?
The unit requires a 220VAC power source with a power consumption of less than 6W.
From: Integram SDPIP-100 Picture-in-Picture Processor User Manual
