Featured Yuanke manuals
Yuanke YK-P3WP45R0T14-60 3W White LED Datasheet
The document provides a comprehensive specification sheet for the Yuanke YK-P3WP45R0T14-60, a 3W high-power white LED designed for traffic signaling, outdoor and indoor architectural lighting, and portable lighting. Key features include high luminance, high efficiency, and a low thermal resistance of 12K/W. The LED is designed for high current operation with a forward current of 700mA and a typical forward voltage between 3.2V and 3.6V. This manual is written in Chinese.
Covers: Product Nomenclature · Outline Dimensions · Electrical-Optical Characteristics · Typical Characteristic Curves · Reliability Test · Soldering Condition
Latest Yuanke manuals
Yuanke YK-P3WP45R0T14-60 3W White LED Datasheet
Datasheet 10 pages · 507 KB · ZHThis datasheet details the specifications, electrical-optical characteristics, reliability tests, and soldering conditions for the Yuanke YK-P3WP45R0T14-60…
Which document do I need?
Datasheet
Ratings, dimensions and ordering codes, for selection and design work.
Questions answered in Yuanke manuals
Is this product RoHS compliant?
Yes, the product is RoHS compliant.
What is the recommended heat sink surface area for 3W products?
The recommended heat sink effective surface area is greater than or equal to 150 square centimeters.
