Featured JRD manuals
JRD JRD320240C Graphic LCD Module Datasheet
This document is a technical specification sheet (datasheet) for the JRD JRD320240C graphic LCD module. The device utilizes an internal S1D13305 controller chip to support text, graphics, and mixed display modes with a resolution of 320x240 dots.
The manual details hardware specifications including operating voltage (5V), physical dimensions, pinout definitions for the Intel8080 and M6800 microprocessor interfaces, and electrical characteristics. It also provides timing diagrams and a comprehensive list of software command codes for initializing and controlling the display. This manual is written in Chinese.
Covers: 概述 · 特性 · 外形尺寸 · 硬件说明 · 原理简图 · 最大工作范围
Latest JRD manuals
JRD JRD320240C Graphic LCD Module Datasheet
Datasheet 24 pages · 564 KB · ZHTechnical datasheet for the JRD JRD320240C graphic liquid crystal display module featuring a 320x240 dot matrix and S1D13305 controller.
Which document do I need?
Datasheet
Ratings, dimensions and ordering codes, for selection and design work.
Questions answered in JRD manuals
What microprocessor interfaces does the JRD320240C support?
It supports both Intel8080 series and M6800 series MPU operation timing circuits.
How many custom characters can be built by the user?
Users can build up to 64 custom 5x7 dot matrix characters.
