Featured Xiangfan Rongheng Power Electronics manuals
Xiangfan Rongheng DBC-012 Thyristor On-State Peak Voltage Test Bench User Manual
The DBC-012 is a specialized testing device developed by Xiangfan Rongheng Power Electronics based on national standards GB4023--83 and GB4024--83. It is designed to measure the on-state peak current (ITM) and on-state peak voltage (VTM) for various thyristors (KP, KK, KA, KS) and rectifier diodes (ZP, ZK). The device utilizes a stored-energy single-pulse testing method, which ensures short conduction times that make junction temperature rise negligible. Key features include automatic digital display of parameters, simple operation, high accuracy, and good repeatability. This manual is written in Chinese.
Covers: 概述 · 主要技术指标 · 使用方法 · 使用注意事项
Latest Xiangfan Rongheng Power Electronics manuals
Xiangfan Rongheng DBC-012 Thyristor On-State Peak Voltage Test Bench User Manual
User Manual 3 pages · 157 KB · ZHThis manual describes the usage and technical specifications of the Xiangfan Rongheng DBC-012 test bench for measuring on-state peak voltage and current in…
Which document do I need?
User Manual
Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.
Questions answered in Xiangfan Rongheng Power Electronics manuals
What types of thyristors can this device test?
The device is suitable for testing various thyristors including KP, KK, KA, and KS series.
From: Xiangfan Rongheng DBC-012 Thyristor On-State Peak Voltage Test Bench User Manual
What types of rectifier diodes are supported?
It supports testing for ZP and ZK series rectifier diodes.
From: Xiangfan Rongheng DBC-012 Thyristor On-State Peak Voltage Test Bench User Manual
