Featured Amphenol RF manuals
Amphenol RF MMCX Switch Product Leaflet
Product Leaflet 2 pages · 395 KB · EN
The manual details the operation of Amphenol RF's MMCX switch, which is a single pole double throw device designed for transferring one source signal between two outputs. It features a normally closed 'internal output' connected via a PCB trace and a normally open 'external output' that connects to an interface when a connector is mated.
Covers: Operation · Specifications · Electrical Characteristics · Mechanical Characteristics · Material Composition
Latest Amphenol RF manuals
Amphenol RF MMCX Switch Product Leaflet
Product Leaflet 2 pages · 395 KB · ENThis document describes Amphenol RF's manually actuated PCB surface mount single pole double throw switches used to transfer signals between internal and…
Questions answered in Amphenol RF manuals
What is the function of this switch?
It transfers one source signal between two outputs.
What are the frequency and cycle ratings?
The VSWR is 1.4 Maximum from DC to 3 GHz at up to 1,500 cycles.
