Featured SU Coils manuals
SU Coils SU10V/H Series AC Line Filters Datasheet
Datasheet 2 pages · 143 KB · EN
This datasheet provides technical specifications and performance data for the SU10V/H series of common mode AC line filters. Key parameters include rated voltage (250VAC/VDC), withstanding voltage (AC 2400V), insulation resistance, thermal class E, and operating temperature range from -25°C to T.
Covers: Numbering System · Shape and Dimensions · Frequency Characteristic · Common mode Inductance · Impedance vs Frequency
Latest SU Coils manuals
SU Coils SU10V/H Series AC Line Filters Datasheet
Datasheet 2 pages · 143 KB · ENTechnical specifications and performance data for the SU Coils SU10V/H series common mode AC line filters, including electrical ratings and dimensions.
Which document do I need?
Datasheet
Ratings, dimensions and ordering codes, for selection and design work.
Questions answered in SU Coils manuals
What is the rated voltage for these AC line filters?
The rated voltage is 250VAC/VDC.
What is the maximum operating temperature rise allowed?
The maximum temperature rise is 120 degrees Celsius.
