Featured Shenzhen Shuguan Electronic Technology Co., Ltd. manuals
SGR3638B Infrared Remote Control Receiver Module Datasheet
The SGR3638B is a miniaturized infrared remote control receiver module manufactured by Shenzhen Shuguan Electronic Technology Co., Ltd. It integrates a photo detector and preamplifier in a single package with a circular lens to improve reception characteristics and immunity against ambient light. The module is compatible with both TTL and CMOS logic levels and supports various major transmission codes including NEC, Sony, Philips, and Sharp.
Covers: Features · Applications · Code Property · Absolute Maximum Ratings · Recommended Operating Conditions · Electro-Optical Characteristics
Latest Shenzhen Shuguan Electronic Technology Co., Ltd. manuals
SGR3638B Infrared Remote Control Receiver Module Datasheet
Datasheet 5 pages · 82 KB · ENTechnical datasheet for the SGR3638B infrared remote control receiver module, detailing features, specifications, and application circuits.
Which document do I need?
Datasheet
Ratings, dimensions and ordering codes, for selection and design work.
Questions answered in Shenzhen Shuguan Electronic Technology Co., Ltd. manuals
What transmission codes does the SGR3638B support?
The module supports NEC, Zenith, Grundig, RCA, Thomson, Philips, Sharp, Sony, Matsushita, Toshiba, Mitsubishi, and RCS-80 codes.
From: SGR3638B Infrared Remote Control Receiver Module Datasheet
What is the minimum burst length required for operation?
The product requires a burst length of at least 10 cycles per burst.
From: SGR3638B Infrared Remote Control Receiver Module Datasheet
