Featured Jizhidazhixin manuals
Jizhidazhixin RemoDAQ-8054 Module User Manual
The RemoDAQ-8054 is a data acquisition and control module designed specifically for the telecommunications industry. It features eight channels for detecting cable continuity (open or short circuits) and includes LED indicators to display the status of each channel. The module operates on a 44V~58VDC power supply. This manual is written in Chinese.
Covers: Overview · Terminal Distribution and Parameters · Connection Instructions · Default Settings · Jumper Settings · Command Format
Latest Jizhidazhixin manuals
Jizhidazhixin RemoDAQ-8054 Module User Manual
User Manual 16 pages · 187 KB · ZHThis manual provides operating instructions for the Jizhidazhixin RemoDAQ-8054, an 8-channel cable continuity detection module for telecom applications.
Which document do I need?
User Manual
Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.
Questions answered in Jizhidazhixin manuals
How do I activate the INIT mode to reset configuration?
To activate INIT mode, turn off power, short the INIT* terminal to GND, then turn on power.
What does it mean if an LED is lit or off?
When a cable is shorted, the LED turns off; when a cable is open (broken), the LED lights up.
