Featured Yatelian manuals
Yatelian YM04-CM03 Gyroscope Module Datasheet
The document is a product specification sheet for the Yatelian YM04-CM03-PCBA digital gyroscope module. It describes a device designed to measure angular velocity and angle under high-precision dynamic conditions using internal sensors and microcontrollers with advanced signal processing algorithms.
Key specifications include physical dimensions of 17.78mm x 15.24mm, an operating voltage range of 2.4V to 3.6V, and a working temperature range from -40°C to +80°C. The module supports UART or I2C output protocols depending on the customer's main controller requirements. This manual is written in Chinese.
Covers: 1 Function Description · 2 Mechanical Specifications · 3 Interface Definition · 4 Electrical Characteristics · 5 Performance Specification · 6 UART Interface
Latest Yatelian manuals
Yatelian YM04-CM03 Gyroscope Module Datasheet
Datasheet 11 pages · 743 KB · ZHThis datasheet describes the Yatelian YM04-CM03 digital gyroscope module, detailing its mechanical specs, electrical characteristics, and UART/I2C interface…
Which document do I need?
Datasheet
Ratings, dimensions and ordering codes, for selection and design work.
Questions answered in Yatelian manuals
What are the supported output protocols?
The module can output via UART or I2C protocol based on customer needs.
How is the UART baud rate configured?
The default UART baud rate is set to 38400 bps.
