Featured Shanghai Shijie Electronic manuals
Shanghai Shijie Electronic S6116 12-bit 16-Channel Analog Input Network Module User Manual
The S6116 is a high-end, high-speed analog acquisition network module manufactured by Shanghai Shijie Electronic. It features 16 input channels utilizing a 12-bit AD converter with a sampling rate of 100k, supporting various signal types including 0-10V, 0-5V, 4-20mA, NTC thermistors, and dry contacts. The module is designed for high stability in industrial automation and monitoring systems. This manual is written in Chinese.
Covers: Overview · Technical Parameters · Wiring Instructions · Human-Machine Interface · Register List · Input Configuration
Latest Shanghai Shijie Electronic manuals
Shanghai Shijie Electronic S6116 12-bit 16-Channel Analog Input Network Module User Manual
User Manual 8 pages · 314 KB · ZHThis manual covers the operation, configuration, and communication protocols for the S6116, a high-speed 16-channel analog input module supporting Ethernet…
Which document do I need?
User Manual
Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.
Questions answered in Shanghai Shijie Electronic manuals
What are the supported input signal types?
The module supports 0-5V, 0-10V, 4-20mA, NTC thermistors, and dry contacts.
From: Shanghai Shijie Electronic S6116 12-bit 16-Channel Analog Input Network Module User Manual
What are the output communication protocols?
The output supports Ethernet with MODBUS/TCPIP protocol or RS485 with standard MODBUS/RTU.
From: Shanghai Shijie Electronic S6116 12-bit 16-Channel Analog Input Network Module User Manual
