Featured KRXGK manuals
KRXGK KPCI-842 Optically Isolated Digital Input Card User Manual
The KPCI-842 interface card is designed for PCI bus slots in original, compatible, and industrial control computers. It is widely used in industrial process control systems and laboratory applications for monitoring changes in switch states. The card connects to external devices via a 37-pin D-type connector on the card.
The document details the installation process, including static discharge precautions and pin definitions for the 32 digital input channels (DI). It also covers the installation of the driver software and provides specific library function examples for Visual C++ and Visual Basic to read and write data from the card. This manual is written in Chinese.
Covers: Product Overview · Main Technical Parameters · Usage Environment · Installation Instructions · Socket Interface Definition · Driver Installation and Testing
Latest KRXGK manuals
KRXGK KPCI-842 Optically Isolated Digital Input Card User Manual
User Manual 10 pages · 585 KB · ZHThis manual provides installation, driver setup, and programming instructions for the KRXGK KPCI-842 optically isolated digital input card.
Which document do I need?
User Manual
Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.
Questions answered in KRXGK manuals
What is the input signal range for the KPCI-842?
The input signal range is 5-48V.
From: KRXGK KPCI-842 Optically Isolated Digital Input Card User Manual
What is the isolation voltage of the card?
The isolation voltage is 500V.
From: KRXGK KPCI-842 Optically Isolated Digital Input Card User Manual
