Featured UNI-ROYAL manuals
UNI-ROYAL MGR Series Metal Glaze Film Fixed Resistors Data Sheet
This document provides a comprehensive data sheet for UNI-ROYAL Metal Glaze Film Fixed Resistors (MGR series). It details the part number system, ordering procedures, and physical dimensions for various power ratings ranging from 1/4W to 3W, including normal, small, and ultra-small sizes. The resistors feature a metal glaze film made of Ruthenium Oxide on a rod-type ceramic body.
Covers: Scope · Part No. System · Ordering Procedure · Marking · Dimension & Resistance Range · Derating Curve
Latest UNI-ROYAL manuals
UNI-ROYAL MGR Series Metal Glaze Film Fixed Resistors Data Sheet
Datasheet 7 pages · 837 KB · ENTechnical datasheet for UNI-ROYAL MGR series metal glaze film fixed resistors, covering specifications, part numbering, dimensions, and performance limits.
Which document do I need?
Datasheet
Ratings, dimensions and ordering codes, for selection and design work.
Questions answered in UNI-ROYAL manuals
What is the part number system for UNI-ROYAL MGR resistors?
The standard Part No. includes 14 digits indicating type, wattage, tolerance, resistance value, and packaging.
From: UNI-ROYAL MGR Series Metal Glaze Film Fixed Resistors Data Sheet
What material is used for the resistor film?
The resistor film is made of Ruthenium Oxide.
From: UNI-ROYAL MGR Series Metal Glaze Film Fixed Resistors Data Sheet
