Featured JLX manuals
JLX JLX128128G-610-PN LCD Module User Manual
The JLX128128G-610-PN is a character and graphic LCD module featuring a 128x128 dot matrix display. It supports single-color or 4-gray-scale image display, as well as Chinese characters and ASCII text in various font sizes (16x16, 8x16, 5x8). The module utilizes the ST7571 driver IC and includes a built-in white LED backlight. This manual is written in Chinese.
Covers: Overview · Character Module Features · Dimensions and Pin Functions · Basic Principles · Technical Parameters · Timing Characteristics (SPI/Parallel/I2C)
Latest JLX manuals
JLX JLX128128G-610-PN LCD Module User Manual
User Manual 28 pages · 409 KB · ZHThis manual covers the specifications, interface pinouts, timing characteristics, and programming examples for the JLX JLX128128G-610-PN monochrome LCD module.
Which document do I need?
User Manual
Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.
Questions answered in JLX manuals
What interfaces does the JLX128128G-610-PN support?
The module supports I²C bus, 4-line SPI serial port, and parallel ports (6800 or 8080 timing).
What is the maximum operating current for the backlight?
The backlight working current ranges from 32mA to 80mA.
