Featured Wuhan HengDian GaoCe Electric manuals
Wuhan HengDian GaoCe Electric HDQH-55 SF6 Gas Recovery and Purification Device User Manual
The HDQH-55 is a mobile, refrigerated SF6 gas recovery and purification system designed for manufacturing, testing and research of SF6‑insulated equipment. It extracts, dries, purifies, compresses and stores SF6 gas, supporting both gas and liquid storage modes.
The manual includes an overview of the system, a step‑by‑step workflow, descriptions of major components, technical performance parameters, configuration details, accessory scope and required documentation. This manual is written in Chinese.
Covers: Overview · Workflow Description · Component Advantages · Technical Performance Parameters · Component Functions · Configuration Parameters
Latest Wuhan HengDian GaoCe Electric manuals
Wuhan HengDian GaoCe Electric HDQH-55 SF6 Gas Recovery and Purification Device User Manual
User Manual 8 pages · 999 KB · ZHUser manual for the HDQH-55 SF6 gas recovery and purification device, detailing workflow, components, specifications and operation.
Which document do I need?
User Manual
Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.
Questions answered in Wuhan HengDian GaoCe Electric manuals
What is the power supply requirement for the device?
The system operates on three‑phase AC 380 V ±10 % at 50 Hz.
From: Wuhan HengDian GaoCe Electric HDQH-55 SF6 Gas Recovery and Purification Device User Manual
How much SF6 can the storage tank hold?
The integrated storage tank is sized for 50 kg of SF6.
From: Wuhan HengDian GaoCe Electric HDQH-55 SF6 Gas Recovery and Purification Device User Manual
