Featured Van Guard manuals
Vanguard M19 Baja Engine Setup Manual
This document is a setup and adjustment guide for the Vanguard M19 Baja engine, specifically designed for SAE Baja racing events. It details the necessary tools, such as the Vanguard tachometer and adjustment wrench, and outlines safety warnings regarding moving parts and hot surfaces.
The guide covers the installation of the SAE Baja specific parts kit (part number 695221), which includes components for the throttle return spring and a specialized fuel cap. It provides step-by-step instructions for installing the throttle return spring, setting the idle speed to a recommended 1750 RPM, and adjusting the maximum no-load speed to 3800 RPM. This manual is written in Chinese.
Covers: Safety Warnings · Required Tools · SAE Baja Parts Kit · Throttle Return Spring Installation · Idle Speed Setting · Maximum Speed Setting
Vanguard TT-V2P Tracker Maintenance Manual
The document serves as a standard maintenance guide for the Vanguard TT-V2P tracker system. It outlines a schedule of preventive maintenance tasks to be performed annually, including the verification of torque tightening values, inspection of electrical connections, and checking operational parameters like tilt angles and wind signals.
Specific procedures are detailed for inspecting structural elements such as piles heads, galvanization, plastic bearings, and linear actuators. The manual also addresses battery preservation modes based on energy levels and temperature-dependent operation limits to ensure system longevity.
Covers: Preventive maintenance · Verification of torque tightening values · Maintenance check of electrical connections · Inspection of galvanization · Plastic bearing inspection · Checking operational parameters
Latest Van Guard manuals
Vanguard M19 Baja Engine Setup Manual
Service Manual 7 pages · 844 KB · ZHThis manual provides instructions for setting up and adjusting the Vanguard M19 Baja engine for SAE Baja competition, including idle and maximum RPM settings.
Vanguard TT-V2P Tracker Maintenance Manual
Service Manual 17 pages · 2.6 MB · ENThis manual provides maintenance instructions for the Vanguard TT-V2P solar tracker, covering preventive checks, torque verification, and emergency procedures.
Which document do I need?
Service Manual
Disassembly, diagnostics and part numbers, for repair.
Questions answered in Van Guard manuals
What is the recommended idle speed for the Vanguard M19 Baja engine?
The recommended idle speed is 1750 RPM.
What is the maximum no-load speed setting for the engine?
The maximum no-load speed can be set to 3800 RPM.
How often should torque tightening values be verified?
The verification of a correct torque tightening value for tracker bolts must be performed on an annual basis.
What is the procedure if rust is found during inspection?
Rusted areas must be repaired immediately by eliminating rust particles and applying zinc-rich paint to protect the surface.
