Featured Sonardyne manuals
Sonardyne Ranger 2 Acoustic Positioning System Product Leaflet
The Sonardyne Ranger 2 is a survey-grade Ultra-Short Baseline (USBL) acoustic positioning system designed for deep water, long-range tracking of underwater targets such as ROVs, towfish, and AUVs. It serves as a position reference for dynamically positioned (DP) vessels by calculating the position of subsea targets through range and bearing measurements from vessel-mounted transceivers to target transponders.
The system is available in two versions: the standard configuration tracks up to 10 simultaneous subsea targets, while the Ranger 2 Pro version supports tracking an unlimited number of targets with features like multiple transceiver interfacing and subsea INS integration. The system utilizes Sonardyne's Wideband 2 signal architecture for precise ranging and fast data telemetry.
Covers: Ranger 2 at a glance · System Configuration · Acoustic Transceiver · Vessel Reference Sensors · 6G Subsea Transponders · Transponder Options
Sonardyne AST 7904 Acoustic Switch Transponder Datasheet
The Type 7904 Acoustic Switch Transponder (AST) is designed to provide Autonomous Underwater Vehicles (AUVs) and Remotely Operated Vehicles (ROVs) with an emergency system that operates independently of all other systems. Reception of a sequence of acoustic commands causes a contact closure within the AST, which can be used to release a weight and cause the vehicle to rise to the surface.
Covers: Description · Key features · Specifications · Operating Frequency · Depth Rating · Battery Life
Sonardyne SPRINT User Manual
The document serves as a comprehensive user guide for the Sonardyne SPRINT system. It covers the introduction to the hardware components, including the Lodestar Attitude Heading Reference System (AHRS) and Inertial Navigation System (INS). The manual details safety procedures, technical descriptions of aiding methods such as USBL, LBL, DVL, and ZUPT, and provides step-by-step instructions for system planning and installation.
Covers: Introduction · Safety · Technical Description · Planning · Installation · Configuration
Latest Sonardyne manuals
Sonardyne Ranger 2 Acoustic Positioning System Product Leaflet
Product Leaflet 4 pages · 3.4 MB · ENA long-range subsea target tracking and DP reference system for deep water operations, supporting unlimited targets with up to 6,000 meters range.
Sonardyne AST 7904 Acoustic Switch Transponder Datasheet
Datasheet 2 pages · 96 KB · ENDatasheet for the Sonardyne AST 7904 Acoustic Switch Transponder, an emergency system for AUVs and ROVs operating in the LF band with ranges up to 10,000…
Sonardyne SPRINT User Manual
User Manual 146 pages · 2.5 MB · ENThis manual provides instructions for the installation, configuration, operation, and maintenance of the Sonardyne SPRINT inertial navigation system.
Which document do I need?
Datasheet
Ratings, dimensions and ordering codes, for selection and design work.
User Manual
Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.
Questions answered in Sonardyne manuals
What types of subsea vehicles does the Ranger 2 track?
The system tracks an unlimited number of targets, including ROVs, towfish, and AUVs.
From: Sonardyne Ranger 2 Acoustic Positioning System Product Leaflet
Does the system support industry standard telegrams?
Yes, it supports all industry standard survey and DP output telegrams.
From: Sonardyne Ranger 2 Acoustic Positioning System Product Leaflet
What is the maximum range of the AST 7904?
The acoustic parameters are set to allow ranges up to 10,000 metres in suitable environmental conditions.
From: Sonardyne AST 7904 Acoustic Switch Transponder Datasheet
How long does the contact closure last?
The contact remains closed for 4 seconds and then opens again.
From: Sonardyne AST 7904 Acoustic Switch Transponder Datasheet
What is the purpose of the 24-hour Emergency Telephone Helpline?
The helpline is for emergency use only to ensure requests are dealt with immediately during office hours and responded to within 30 minutes at all other times.
What is the purpose of the Sonardyne SPRINT?
The SPRINT is a system designed for Inertial Navigation.
