BenQ FP73G S LCD Color Display User Manual
This manual provides safety instructions, cleaning guidelines, and step‑by‑step hardware installation for the BenQ FP73G S 19‑inch LCD monitor. It covers power connection, cable selection, and mounting options, as well as troubleshooting tips and FAQ.
The document also lists detailed technical specifications such as display type, resolution, contrast, brightness, response time, power consumption, and input options (RGB analog and optional DVI‑D). This manual is written in Chinese.
BenQ FP73G specifications
| Display Type | 19.0" active TFT |
|---|---|
| Resolution | 1280 x 1024 |
| Contrast Ratio (typical) | 1000:1 |
| Contrast Ratio (minimum) | 600:1 |
| Brightness (typical) | 300 cd/m2 |
| Brightness (minimum) | 250 cd/m2 |
| Response Time (typical) | 5 ms |
| Response Time (maximum) | 8 ms |
| Viewing Angle (typical) | 160/160 (CR>10) |
| Viewing Angle (minimum) | 140/140 (CR>10) |
| Maximum Power Consumption | 40 W |
| Energy‑Saving Mode Power | <1 W |
| Dimensions (W×H×D) | 363.8 x 356.5 x 135 mm |
| Operating Voltage | 100‑240 V, 50‑60 Hz |
All BenQ FP73G documents by type
Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.
Questions answered in these manuals
How should I clean the LCD screen?
Unplug the monitor, then use a non‑abrasive cloth to gently wipe the screen; avoid liquids, wetting agents, or glass cleaners.
Can I use both DVI‑D and D‑Sub cables at the same time?
Do not use both cables on a single PC; they can be used simultaneously only when each cable is connected to a separate video source.
How should I clean the LCD screen?
Unplug the monitor, then wipe the screen with a non‑abrasive cloth and avoid any liquids or cleaning agents.
What power voltage does the monitor accept?
The monitor operates on an automatic‑switching power input of 90‑264 V at 47‑63 Hz.
