SINO Manuals

Key facts

Manuals

26

Models

6

Languages

ZH · EN

Last added

2012-06-05

SINO models by category

Featured SINO manuals

SINO SH69P461 Microcontroller Programming Manual

User Manual 40 pages · 383 KB · ZH

The SH69P461 is a CMOS 4‑bit microcontroller that integrates a CPU core, 2 K×16‑bit OTP ROM, 123×4‑bit RAM, 35 system control registers, 88 data memory locations, a 5‑channel 8‑bit ADC, dual PWM outputs and a comparator. It is intended for DC fan applications and offers flexible clocking options.

The manual provides a complete description of the pin configuration, register map, instruction set, system initialization, oscillator selection, and package dimensions. It also includes tables for system register settings and initial reset values. This manual is written in Chinese.

Covers: Features · Pin Configuration · Pin Description · Functional Description · CPU · RAM

SINO SH69P26/K26 Datasheet

Datasheet 42 pages · 487 KB · ZH

The SH69P26/K26 is a 4‑bit CMOS microcontroller that integrates a SH6610D CPU core, RAM, OTP and MASK ROM, two 8‑bit timers, a 16‑bit timer, comparators, dual‑channel audio generator, watchdog timer, low‑voltage reset and various I/O ports. It is intended for use in microwave oven applications and supports multiple low‑power modes (HALT and STOP).

The document provides a complete pin configuration and description, functional block diagram, CPU architecture, RAM organization, system register map, package dimensions, and a change‑record log. It serves as a reference for designers needing detailed electrical and functional information about the device. This manual is written in Chinese.

Covers: Features · Pin Configuration · Pin Description · Functional Description · CPU Architecture · RAM Organization

Sino Wealth SH69K20A User Manual

User Manual 28 pages · 285 KB · ZH

The SH69K20A is a CMOS 4‑bit microcontroller that integrates the SH6610C CPU core, RAM, ROM, timers, and I/O ports. It supports internal RC oscillators at 2 MHz, 4 MHz and 6 MHz and is suitable for general‑purpose applications.

This manual describes the device’s features, pin layout, register map, instruction set, clock options, power requirements, and initial reset states, along with package dimensions and recommended crystal load capacitors. This manual is written in Chinese.

Covers: Features · Overview · Pin Configuration · Pin Description · CPU Architecture · Memory Organization

SINO WEALTH SH66603 4- Position LCD driver Of monolithic micro controller Manual

User Manual 38 pages · 353 KB · ZH

The SH6603 is a 4‑bit monolithic microcontroller that integrates an LCD driver, EL‑LIGHT driver, programmable sound generator, RFC circuit and watchdog timer. It uses the SH6610C core, provides 2048 × 16‑bit ROM, 128 × 4‑bit RAM, and operates from 2.2 V‑3.6 V.

The manual details the pin layout, system registers, port configurations, bonding options, clock sources, low‑power modes (HALT and STOP) and includes typical application circuits and register maps for developers. This manual is written in Chinese.

Covers: Overview · Specifications · Pin Description · CPU Architecture · Memory Map · System Registers

Latest SINO manuals

• SINO AMERICAN HIGH VOLTAGE RECTIFIERS

• SINO WEALTH SH67P54/K54/P53/K53 EVB DATA SHEET

  SH67P54/K54/P53/K53 EVB is an evaluation board used to evaluate the functions of SH67P54/K54/P53/K53 chips and used for application program development.

• SINO WEALTH SH69K20A EVB DATA SHEET

  The SH69K20A EVB is used to evaluate the function of the SH69K20A chip for the development of application programs. It contains a SH69V20A chip to evaluate the functions of SH69K20A.

• SINO WEALTH SH69P21 EVB DATA SHEET

  The SH69P21 EVB is an evaluation board used to evaluate the functions of the SH69P21 chip for the development of application programs. It contains a SH69V21 chip for evaluating the functions of the SH69P21.

• SINO WEALTH SH69P25/P23/P20B EVB DATA SHEET

  This document introduces the design and use of SH69P25/P23/P20B EVB.

• SINO WEALTH SH69P26 EVB DATA SHEET

  SH69P26 EVB is an evaluation board for the SH69P26 chip function for the development of application program.

• SINO WEALTH SH69P31 EVB DATA SHEET

  SH69P31 EVB is an evaluation board for the development of application programs to evaluate the functions of the SH69P31 chip. It contains an SH69V31 chip to evaluate the functions of SH69P31. This document provides detailed instructions for using SH69P31 EVB.

• SINO WEALTH SH69P461/P862/P842/P822/P802/P801 EVB DATA SHEET

  SH69P461/P862/P842/P822/P802/P801 EVB Application Notes introduces the functions and usage of SH69P461/P862/P842/P822/P802/P801 EVB.

• SINO WEALTH SH79F085/SH79F165 Application Note

  This document introduces the features and characteristics of SH79F085/SH79F165 products, including package, software installation, target board setup, etc.

• SINO WEALTH SH88F2051/4051 Application Note

• SINO SH69P461 Microcontroller Programming Manual

  User Manual 40 pages · 383 KB · ZH

  Technical manual for the SINO SH69P461 8‑pin microcontroller, covering features, pinout, registers and programming details.

• SINO SH69P26/K26 Datasheet

  Datasheet 42 pages · 487 KB · ZH

  Technical datasheet for the SH69P26/K26 4‑bit CMOS microcontroller, detailing specifications, pinout, and register map.

• SINO WEALTH SH79F163 integration LCD drive function Of enhanced 8051 Micro- CPU Manual

• Sino Wealth SH69K20A User Manual

  User Manual 28 pages · 285 KB · ZH

  The Sino Wealth SH69K20A user manual provides specifications, pin configurations, instruction set, and operating details for the 4‑bit CMOS microcontroller.

• SINO WEALTH SH66603 4- Position LCD driver Of monolithic micro controller Manual

  User Manual 38 pages · 353 KB · ZH

  Technical manual for the SH6603 4‑position LCD driver monolithic microcontroller, covering architecture, pins, registers and operation.
