Zebra 888-DT Desktop Print Table Machine User Manual
This manual covers the installation and wiring of the Zebra 888-DT desktop print table machine, including connector types, power requirements, and communication settings. Detailed diagrams show the RS‑232 and USB connections, pin assignments, and voltage levels.
Operational guidance includes start‑up procedures, normal use, maintenance tips, and a troubleshooting section that addresses common error conditions and LED indicators. This manual is written in Chinese.
Zebra 888 specifications
| Print speed | 102 mm/s |
|---|---|
| Print resolution | 203 dpi |
| SRAM | 256 KB |
| Supported media width | 25.4 mm |
| Interfaces | RS232 serial, USB, optional Ethernet (ZebraNet PrintServer) |
All Zebra 888 documents by type
Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.
Questions answered in these manuals
What is the print resolution of the Zebra 888?
The printer provides a resolution of 203 dpi.
What is the maximum print speed of the Zebra 888?
The printer can print at up to 102 mm per second.
What print resolution does the Zebra 888 support?
It supports 203 dpi resolution, with an optional 300 dpi mode.
Which interfaces are available on the Zebra 888 printer?
The printer provides serial, parallel, and USB interfaces.
What connector type is used for RS‑232 communication?
The RS‑232 interface uses a DB‑9 connector.
What is the default baud rate for the device?
The default communication speed is 9600 baud.
