User manual for the SVP pressure transmitter, covering installation, wiring, operation, specifications and fault codes.
This manual provides detailed instructions for installing and wiring the SVP pressure transmitter. It includes step‑by‑step procedures, wiring diagrams, and safety precautions for proper setup.
The document also describes the operation of the device, lists technical specifications such as output current range and power requirements, and explains fault codes and calibration methods to ensure reliable performance. This manual is written in Chinese.
| Output current range | 4-20 mA DC |
|---|---|
| Typical output current | 3.85 mA to 24 mA |
| Current measurement steps | 4 mA, 8 mA, 12 mA, 16 mA, 20 mA |
The SVP provides a 4‑20 mA DC output current range.
