The 74LVT16373A is a high-performance BiCMOS product designed for VCC operation at 3.3V. This device is a 16-bit transparent D-type latch with non-inverting 3-State bus compatible outputs. The device can be used as two 8-bit latches or one 16-bit latch. When enable (E) input is High, the Q outputs follow the data (D) inputs. When enable is taken Low, the Q outputs are latched at the levels of the D inputs one setup time prior to the High-to-Low transition.
The document describes the Philips 74LVT16373A, a high-performance BiCMOS integrated circuit designed for VCC operation at 3.3V. It functions as a 16-bit transparent D-type latch or two separate 8-bit latches, featuring non-inverting 3-State bus compatible outputs.
| Supply Voltage (VCC) | 3.3V |
|---|---|
| Data Width | 16-bit |
| Output Type | non-inverting 3-State |
| Propagation Delay (Typical) | 19 ns |
| Output Capability | +64mA/-32mA |
| Operating Temperature Range | -40°C to +85°C |
Yes, the device can be configured to function as either two 8-bit latches or one single 16-bit latch.
No, the built-in bus-hold data inputs eliminate the need for external pull-up resistors to hold unused inputs.
Yes, the device supports live insertion and extraction of components.
