EXTECH 412440 Current Loop Checker user manual

Update: 28 September, 2023

This document describes a low-cost, pocket-sized current loop checker. It simulates output ranges of 4mA, 12mA, and 20mA from a transmitter and is ideal for checking calibration and serving as a current source for setting up engineering units on a process indicator or controller. The checker is accurate to 0.1mA and provides overload indication when the load exceeds 240Ω. It features a compact case with a push button output selector switch.

Brand: EXTECH

File format: PDF

Size: 163 KB

MD5 Checksum: 39F000EB867701B48119953721127052

Publication date: 01 August, 2012

Downloads: -

PDF Link: EXTECH 412440 Current Loop Checker user manual PDF

Download
