FAIRCHILD FSL206MR handbook

FSL206MR is a green mode Fairchild Power Switch (FPS) with an integrated Pulse-Width Modulator (PWM) and SenseFET from Fairchild Semiconductor Corporation. The product has a fixed operating frequency, low power consumption, no need for auxiliary bias winding, frequency modulation to reduce EMI, line under-voltage protection (LUVP), pulse current limiting, low under-voltage lockout (UVLO), ultra-low operating current, built-in soft-start and startup circuit, various protections (overload protection (OLP), overvoltage protection (OVP), thermal shutdown (TSD), abnormal overcurrent protection (AOCP)) and automatic restart mode.

Brand: Fairchild

File format: PDF

Size: 885 KB

MD5 Checksum: F0C04E9C64E59D84EEF3C57A69A5DBBA

Publication date: 12 July, 2012

Downloads: -

PDF Link: FAIRCHILD FSL206MR handbook PDF

Download
