TEXAS ISNTRUMENTS PT4560 Series handbook

Update: 30 September, 2023

The PT4560 series is a single-output isolated DC/DC converter from TI, with a power rating of 30 watts and an output current of 8 A. The input voltage range is 36V to 75V, and the output voltage can be adjusted from 1.8 V to 15 V. This series features remote on/off control, under-voltage-lockout (UVLO), and a differential remote sense. It also includes output current limit, short-circuit protection, and over-temperature shutdown.

---

File format: PDF

Size: -

MD5 Checksum: F434A1A356F81CFC103B6463263C8F22

Publication date: 11 June, 2012

Downloads: -

PDF Link: TEXAS ISNTRUMENTS PT4560 Series handbook PDF
